XiVision WiFi HaLow Outdoor AP Extender - IEEE 802.11ah & 2.4G Suitable for Long Distance Wifi Range Extender Amplifier
XiVision WiFi HaLow Outdoor AP Extender - IEEE 802.11ah & 2.4G Suitable for Long Distance Wifi Range Extender Amplifier
Couldn't load pickup availability
Notice:We provide 3 frequencies USA: 902-928MHz EU: 863-868MHz Japan: 916.5-927.5MHz. We will send the wifi Halow extender with the corresponding frequency according to the country/region where the customer orders. If you have special frequencies, please contact us
XiVision WiFi HaLow Outdoor AP Extender


AH WiFi HaLOW Extender point-to-point long-distance wireless access, 20DBi high-gain antenna, 100Mbps 2.4G WiFi Halow Extender, supports 3000 feet of outdoor transmission distance, the distance through the wall can reach 300M, Wifi penetration is stronger, to achieve mobile wifi full coverage, Easy to carry, no need to set up USB plug and play, suitable for outdoors, gardens, apartments, can transmit wifi signal to any network device



Description:
The Wi-Fi Halow standard network bridge works on the 902-928MHz frequency.
The model is dedicated to cost-effective solutions for wireless networking applications.
It is ideal for point-to-point signal coverage applications.
Professional performance, coupled with user-friendly design, makes the model an ideal choice for both business and home users. Compare with the traditional  WiFi Extender or the CPE, the model is the first device with an Omnidirectional antenna for the 1Km signal transmission or strong penetration capability.


Product specifications and parameters
parameter |
explain |
Protocol |
IEEE 802.11ah,(902-928MHz)IEEE 802.11b/g/n(2412-2472MHz) |
Communication bandwidth |
8MHz |
data rate |
maximum 16Mbps |
Receiver sensitivity |
1M PPDU MCS=10 -105dbm;8M PPDU MCS=0 -95dbm;8M PPDU MCS=7 -81dbm |
Number of supported network nodes |
Up to 8 access points |
transmit power |
20dBm 100mW |
debugging method |
BPSK,QPSK,QAM16 or QAM64 |
Transmission distance |
The maximum distance is 1000 meters, and the non-communication distance is 300 M |
safety regulations |
WPA2-PSK |
Encryption |
AES |
Network port |
10/100Mbps |
power supply |
Type-c5V/1A |
LED light indication |
Power Indicator connection indicator Link indicator |
Antenna interface |
built-in antenna |
Input voltage |
5V1A |
Maximum current |
500mA |
Working average power consumption |
1.5W |
Operating temperature |
-20 ℃ ~ 70 ℃ |
storage temperature |
-30 ℃ ~ 80 ℃ |
Working humidity |
10%~90% |
storage humidity |
5%~95% |
Product Size |
53(diameter)x18.6(high)mm |
product weight |
120g |
